Bromic Platinum Smart-Heat Electric Heater Black or White Patio Heater
Starts at: $1,289.00
The Platinum Smart-heat Electric Heater is the top of the food chain when it comes to smart-heating range heaters. It’s the perfect blend between quality radiant heat and style. These ultra-thin heaters are designed to give off directional heat and be a seemless transition for both commercial and residential applications. Come rain or shine Platinum Stylish Heaters are not effected by wind and will still provide a soft and radiant heat. Multiple heaters can be controlled from a single remote.
Features:
- 2300W, 3400W & 4500W output
- Ultra thin and new style
- Brushed Stainless Steel
- Straight and angled bracket
- Water resistant and wind resistant
- Can use smart control systems
- One or more units can be switched on or
- off from a single remote.
- Click Here for installation, instruction and service manual






Specifications
Model Number | Product Codes | Fuel Type | Color | Heat Area | Rated Current | Minimum Floor Clearance |
---|---|---|---|---|---|---|
2300W SERIES | BH0320003 | BH0320007 | Electric | Black | White | 65² | 230 – 240V/9.6A | WALL 72” | CEILING 96” |
3400W SERIES | BH0320005 | BH0320008 | Electric | Black | White | 108² | 230 – 240V/14.2A | WALL 72” | CEILING 96” |
Mounting Options
Model Number | Ceiling Mount | Ceiling Recess Kit Product Codes | Wall Mount | Recessed | Flush Mount | Cieling Pole Mount | Ceiling Pole (2’) Product Code | Ceiling Pole (4’) Product Code | Freestanding |
---|---|---|---|---|---|---|---|---|
2300W SERIES | Yes | BH3130017 | Yes | Yes | Yes | BH3130023 | BH3130024 | No |
3400W SERIES | Yes | BH3130027 | Yes | Yes | Yes | BH3130023 | BH3130024 | No |
Control Options
On/Off Control & Dimmer Control: 1 CH = Channel Input, each Channel Input can control up to 6000 Watts of power or 10 gas heaters. Below chart explains each model and how many heaters can be used per CH (Channel).
On/Off Controller: Heater(s) can be turned on or off at full power capacity, providing straight forward function and usage of your outdoor heater(s). Using the enabled Wi-Fi (compatible with 2.4GHz) or Bluetooth connectivity, control and customize your comfort via the Bromic Heating App.
Dimmer Controllers: Using the Bromic Heating App, you can instantly and precisely adjust heat output down to 1% increments and other unique scenes and settings for ideal outdoor experiences. Using the enabled Wi-Fi (compatible with 2.4 GHz) or Bluetooth connectivity, control and customize your comfort via the Bromic Heating App.
On/Off Control & Dimmer Control: Neither come with a remote. Wi-Fi and Bluetooth only.
Wattage | Item Number | On | Off 1 CH BH3130051 | On | Off CH 2 BH3130052 | On | Off 5 CH BH3130053 | Dimmer 1 CH BH3130061 | Dimmer 2 CH BH3130062 | Dimmer 5 CH BH3130063 |
2300 SERIES | BH0320003 240V BLACK BH0320007 240V WHITE | 2 HEATERS (PER CH) | 4 HEATERS (2 PER CH) | 10 HEATERS (2 PER CH) | 2 HEATERS (PER CH) | 4 HEATERS (2 PER CH) | 10 HEATERS (2 PER CH) |
3400 SERIES | BH0320005 240V BLACK BH0320008 240V WHITE | 1 HEATER (PER CH) | 2 HEATERS (1 PER CH) | 5 HEATERS (1 PER CH) | 1 HEATER (PER CH) | 2 HEATERS (1 PER CH) | 5 HEATERS (1 PER CH) |
4500 SERIES | BH3622000 240V BLACK BH3622001 240V WHITE | 1 HEATER (PER CH) | 2 HEATERS (1 PER CH) | 5 HEATERS (1 PER CH) | 1 HEATER (PER CH) | 2 HEATERS (1 PER CH) | 5 HEATERS (1 PER CH) |
2300 SERIES | BH0320019 208V BLACK BH0320020 208V WHITE | 2 HEATERS (PER CH) | 4 HEATERS (2 PER CH) | 10 HEATERS (2 PER CH) | 2 HEATERS (PER CH) | 4 HEATERS (2 PER CH) | 10 HEATERS (2 PER CH) |
3400 SERIES | BH0320021 208V BLACK BH0320022 208V WHITE | 1 HEATER (PER CH) | 2 HEATERS (1 PER CH) | 5 HEATERS (1 PER CH) | 1 HEATER (PER CH) | 2 HEATERS (1 PER CH) | 5 HEATERS (1PER CH) |
4500 SERIES | BH3622004 208V BLACK BH3622005 208V WHITE | 1 HEATER (PER CH) | 2 HEATERS (1 PER CH) | 5 HEATERS (1 PER CH) | 1 HEATER (PER CH) | 2 HEATERS (1 PER CH) | 5 HEATERS (1 PER CH) |
NOTE: | Platinum 4500W-All Models, Individual Element Control | N/A | 1 ELEMENT PER CH | N/A | N/A | N/A | N/A |
Additional information
Wattage | 2300 Watts, 3400 Watts, 4500 Watts |
---|---|
Finish | Black, White |
Fuel Type | Electric |
